Description
This Switch is lightweight and perfect for use with other accessories.
Perfect for any enduro, street bike, off-road bike or ATV and many more.
Specifications:
Item type – Handlebar control – 5 function (1. Light off/low/high, 2. Engine kill button, 3. Electric start, 4. Horn, 5. Indicators)
Material type – Water-resistant plastic.
Connector type – Plug 1 – female 4-pin connector with 4 wires, female 9-pin connector with 8 wires.
Fits – Any 12V electrical system.
Switch width – 47mm
Switch height – 75mm
Switch depth – 80mm
Cable length – 610mm
Wiring Information:
Power feed
Black – 12V power in for Lights, flasher and horn
Lights
Blue – Lights (high beam)
White – Lights (dipped beam)
Yellow – Side light
Indicators
Grey – Indicators (power in)
Light Blue – Indicators right
Orange – Indicators left
Kill switch
Green – Kill switch
Brown – Kill switch
Horn
Light Green – Power out to the horn accessory
Electric start
Green/Yellow – Electric start
YellowRed – Electric start
Please check the specifications above to make sure it fits your bike and is suitable for your motorcycle, dirt bike or ATV or pit bike.
This product is a universal fitment and will fit most machines on-road and off-road that are fitted with regular 22mm handlebars
